Component-wise Arithmetic Operations on Matrices and Vectors

In the following we show some examples for coding component-wise operations on matrices and vectors. The notation that FLENS provides for coding such operations closely follows the typical mathematical notation:

Simply write down the operation component-wise!

The examples will briefly cover the following topics:

  1. Initialize matrices and vectors component-wise:
  2. Perform some mathematical operations (e.g. sin, cos,... basically all the stuff from cmath) component-wise
  3. Simple component-wise summation
  4. Define your own component-wise mathematical operation
  5. List of supported mathematical component-wise operations in FLENS

Initialize matrices and vectors component-wise

In this example we will deal with

The matrices and vectors will be initialized as follows:

As you can see, this can be coded close to the mathematical notation in an expressive way:

demo/cwise_init.cc
#include <flens/flens.h>

using namespace flens;
using namespace std;

typedef GeMatrix<FullStorage<double, ColMajor> >    DGeMatrix;
typedef DenseVector<Array<double> >                 DDenseVector;

int
main()
{
    int n = 8;

    Index i,j;

    DDenseVector x(n), y(n), z(n);
    DGeMatrix    A(n,n), B(n,n), C(n,n);


    x(i) = sin(2*M_PI*i/n);
    y(i) = i/double(n);
    z(i) = max(x(i), cos(2*M_PI*y(i)));
    A(i,j) = i + j;
    B(i,j) = x(i)*y(j);
    C(i,j) = M_PI*A(i,j) + x(i)*B(i,j);

    cout << "x = " << x << endl;
    cout << "y = " << y << endl;
    cout << "z = " << z << endl;
    cout << "A = " << A << endl;
    cout << "B = " << B << endl;
    cout << "C = " << C << endl;
}

This will produce the following result:

x = [ 0.707107  1.000000  0.707107  0.000000  -0.707107  -1.000000  -0.707107  -0.000000 ]

y = [ 0.125000  0.250000  0.375000  0.500000  0.625000  0.750000  0.875000  1.000000 ]

z = [ 0.707107  1.000000  0.707107  0.000000  -0.707107  -0.000000  0.707107  1.000000 ]

A = [8, 8]
   2.000000    3.000000    4.000000    5.000000    6.000000    7.000000    8.000000    9.000000 ;
   3.000000    4.000000    5.000000    6.000000    7.000000    8.000000    9.000000   10.000000 ;
   4.000000    5.000000    6.000000    7.000000    8.000000    9.000000   10.000000   11.000000 ;
   5.000000    6.000000    7.000000    8.000000    9.000000   10.000000   11.000000   12.000000 ;
   6.000000    7.000000    8.000000    9.000000   10.000000   11.000000   12.000000   13.000000 ;
   7.000000    8.000000    9.000000   10.000000   11.000000   12.000000   13.000000   14.000000 ;
   8.000000    9.000000   10.000000   11.000000   12.000000   13.000000   14.000000   15.000000 ;
   9.000000   10.000000   11.000000   12.000000   13.000000   14.000000   15.000000   16.000000 ;

B = [8, 8]
   0.088388    0.176777    0.265165    0.353553    0.441942    0.530330    0.618718    0.707107 ;
   0.125000    0.250000    0.375000    0.500000    0.625000    0.750000    0.875000    1.000000 ;
   0.088388    0.176777    0.265165    0.353553    0.441942    0.530330    0.618718    0.707107 ;
   0.000000    0.000000    0.000000    0.000000    0.000000    0.000000    0.000000    0.000000 ;
  -0.088388   -0.176777   -0.265165   -0.353553   -0.441942   -0.530330   -0.618718   -0.707107 ;
  -0.125000   -0.250000   -0.375000   -0.500000   -0.625000   -0.750000   -0.875000   -1.000000 ;
  -0.088388   -0.176777   -0.265165   -0.353553   -0.441942   -0.530330   -0.618718   -0.707107 ;
  -0.000000   -0.000000   -0.000000   -0.000000   -0.000000   -0.000000   -0.000000   -0.000000 ;

C = [8, 8]
   6.345685    9.549778   12.753871   15.957963   19.162056   22.366149   25.570241   28.774334 ;
   9.549778   12.816371   16.082963   19.349556   22.616149   25.882741   29.149334   32.415927 ;
  12.628871   15.832963   19.037056   22.241149   25.445241   28.649334   31.853427   35.057519 ;
  15.707963   18.849556   21.991149   25.132741   28.274334   31.415927   34.557519   37.699112 ;
  18.912056   22.116149   25.320241   28.524334   31.728427   34.932519   38.136612   41.340704 ;
  22.116149   25.382741   28.649334   31.915927   35.182519   38.449112   41.715704   44.982297 ;
  25.195241   28.399334   31.603427   34.807519   38.011612   41.215704   44.419797   47.623890 ;
  28.274334   31.415927   34.557519   37.699112   40.840704   43.982297   47.123890   50.265482 ;

Perform some mathematical operations component-wise

In this example we will deal with vectors

We initialize vectors and component-wise with and . This is followed by the component-wise computation of

Again the code realizing this should be pretty much self-explanatory ...

demo/cwise_cmath.cc
#include <flens/flens.h>

using namespace flens;
using namespace std;

typedef DenseVector<Array<double> >                 DDenseVector;

int
main()
{
    int n = 8;

    Index i;

    DDenseVector x(n), y(n), z(n);

    x(i) = i*i;
    y(i) = double(1)/i;

    cout << "x = " << x << endl;
    cout << "y = " << y << endl;

    z(i) = exp(-x(i));
    cout << "z = exp(-x)" << endl << "  = " << z << endl;

    z(i) = exp(1/x(i));
    cout << "z = exp(-x)" << endl << "  = " << z << endl;

    z(i) = log(y(i));
    cout << "z = log(y)" << endl << "  = " << z << endl;

    z(i) = max(exp(1/x(i)), abs(log(y(i))));
    cout << "z = max(exp(1/x), abs(log(y)))" << endl << "  = " << z << endl;

    z(i) = min(0, sin(2*M_PI*i/n));
    cout << "z = min(0, sin(2*M_PI*i/n)" << endl << "  = " << z << endl;
}

And here the result:

x = [ 1.000000  4.000000  9.000000  16.000000  25.000000  36.000000  49.000000  64.000000 ]

y = [ 1.000000  0.500000  0.333333  0.250000  0.200000  0.166667  0.142857  0.125000 ]

z = exp(-x)
  = [ 0.367879  0.018316  0.000123  0.000000  0.000000  0.000000  0.000000  0.000000 ]

z = exp(-x)
  = [ 2.718282  1.284025  1.117519  1.064494  1.040811  1.028167  1.020618  1.015748 ]

z = log(y)
  = [ 0.000000  -0.693147  -1.098612  -1.386294  -1.609438  -1.791759  -1.945910  -2.079442 ]

z = max(exp(1/x), abs(log(y)))
  = [ 2.718282  1.284025  1.117519  1.386294  1.609438  1.791759  1.945910  2.079442 ]

z = min(0, sin(2*M_PI*i/n)
  = [ 0.000000  0.000000  0.000000  0.000000  -0.707107  -1.000000  -0.707107  -0.000000 ]

Simple component-wise summation

In this example we will deal with

We will compute:

demo/cwise_summation.cc
#include <flens/flens.h>

using namespace flens;
using namespace std;

typedef GeMatrix<FullStorage<double, ColMajor> >    DGeMatrix;
typedef DenseVector<Array<double> >                 DDenseVector;

int
main()
{
    int m = 4;
    int n = 8;

    Index i,j;

    DDenseVector x(n), y(n);
    DDenseVector z(m);
    DGeMatrix    A(m,n);

    // some simple initialization
    x(i) = i;
    y(i) = n-i;
    A(i,j) = n*(i-1) + j;

    cout << "x = " << x << endl;
    cout << "y = " << y << endl;
    cout << "A = " << A << endl;

    // ... and here the computations:
    double alpha;

    // alpha = x^T*y
    alpha = sum(x(i)*y(i), i);
    cout << "alpha = " << alpha << endl << endl;

    // z = A*x
    z(i) = sum(A(i,j)*x(j), j);
    cout << "z = " << z << endl;

    // y = A^T*z
    y(j) = sum(A(i,j)*z(i), i);
    cout << "y = " << y << endl;

    // alpha = z^T A x
    alpha = sum(sum(z(i)*A(i,j)*x(j), i), j);
    cout << "alpha = " << alpha << endl;
}

And here the result:

x = [ 1.000000  2.000000  3.000000  4.000000  5.000000  6.000000  7.000000  8.000000 ]

y = [ 7.000000  6.000000  5.000000  4.000000  3.000000  2.000000  1.000000  0.000000 ]

A = [4, 8]
   1.000000    2.000000    3.000000    4.000000    5.000000    6.000000    7.000000    8.000000 ;
   9.000000   10.000000   11.000000   12.000000   13.000000   14.000000   15.000000   16.000000 ;
  17.000000   18.000000   19.000000   20.000000   21.000000   22.000000   23.000000   24.000000 ;
  25.000000   26.000000   27.000000   28.000000   29.000000   30.000000   31.000000   32.000000 ;

alpha = 84.000000

z = [ 204.000000  492.000000  780.000000  1068.000000 ]

y = [ 44592.000000  47136.000000  49680.000000  52224.000000  54768.000000  57312.000000  59856.000000  62400.000000 ]

alpha = 2032704.000000

Define your own component-wise mathematical operation

Assume you want to define your own function dummy that can be applied component-wise to a matrix or vector. This is made very simple if your function dummy takes only one or two arguments, i.e. if your function represents an unary or a binary operation respectively.

If your function takes more than two arguments it is still simple but you have to face more of the internals. For the sake of simplicity we will focus here on a simple example where a function dummy takes only one argument, i.e. represents an unary operation.

Assume dummy is defined as follows:

Then the following example shows how this function can be added to FLENS in a component-wise fashion (see below for an explanation of this code):

demo/cwise_unaryoperation.cc
#include <iostream>
#include <flens/flens.h>

namespace flens {

//== 1) define your own operator type ==
struct OpDummy {};

//== 2) define your own function returning a scalar closure ==
template <typename X>
const typename _SUO_<OpDummy, X>::Type
dummy(const ScalarClosure<X> &x)
{
    typedef typename _SUO_<OpDummy, X>::Engine SUO;
    return SUO(x.engine());
}

//== 3) define how your operation gets evaluated
template <>
struct Operation<OpDummy>
{
    template <typename X>
    static X
    eval(const X &x)
    {
        return x*x-1;  // <- return x^2-1
    }
};

} // namespace flens


using namespace flens;
using namespace std;

typedef GeMatrix<FullStorage<double, ColMajor> >   DGeMatrix;
typedef DenseVector<Array<double> >                DDenseVector;

int
main()
{
    DDenseVector x(5), y(5);


    Index i;

    x(i) = dummy(i);
    cout << "x = " << x << endl;

    y(i) = dummy(x(i));
    cout << "y = " << y << endl;

    double alpha = sum(dummy(y(i)), i);
    cout << "alpha = " << alpha << endl;
}

And here the result:

x = [ 0.000000  3.000000  8.000000  15.000000  24.000000 ]

y = [ -1.000000  8.000000  63.000000  224.000000  575.000000 ]

alpha = 384830.000000

Howto: Defining component-wise mathematical operations

First you have to define a new type representing your operation. You do this by defining an empty struct:

struct OpDummy {};

Second you have to implement a function that returns so called scalar closure objects. Such objects encapsulates an operation and allows delaying its evaluation. Don't worry if this scares you. The implementation follows a rather strict pattern. For an unary operation the rough idea is the following: your function receives an object of type

ScalarClosure<X>

where X denotes some template parameter, then creates an object of type

ScalarUnaryOperation<OpDummy, X>

and finally returns an object of type

ScalarClosure<ScalarUnaryOperation<OpDummy, X> >

For convenience we provide a trait class that eases the handling:

_SUO_<OpDummy, X>::Engine  for  ScalarUnaryOperation<OpDummy, X>
_SUO_<OpDummy, X>::Type    for  ScalarClosure<ScalarUnaryOperation<OpDummy, X> >

We hope that you now have a rough idea what's going on in the code snippet

template <typename X>
const typename _SUO_<OpDummy, X>::Type
dummy(const ScalarClosure<X> &x)
{
    typedef typename _SUO_<OpDummy, X>::Engine SUO;
    return SUO(x.engine());
}

Finally you have to define how your dummy operation gets carried out. You define this in the Operation trait:

template <>
struct Operation<OpDummy>
{
    template <typename X>
    static X
    eval(const X &x)
    {
        return x*x-1;  // <- return x^2-1
    }
};

List of supported mathematical component-wise operations in FLENS

So far the following functions/operations are supported in FLENS. The list basically consists of those functions that can be found in cmath (and we therefore use the same names for functions like acos instead of arccos. But maybe we should support both names in such cases). Feel invited to extend this list:
