Solving a System of Linear Equations

In the following we show some examples for solving a system of linear equations using a LU-factorization. The coefficient matrix in all examples will be a regular, square, non-symmetric matrix:

Theoretical background of the LU-factorization

Let us first recall how to apply the LU-factorization for solving the system of linear equations given by

Using Gaussian elimination one can find a permutation matrix P, a lower unit triangular matrix L and an upper triangular matrix U such that

This constitutes the LU factorization of A. Thus, solving Ax=b is equivalent to solving

which can be done in three steps:

Implementation background of the LU-factorization

Permutation matrix P is defined through row-interchanges carried out during the factorization. Therefore a favorable representation of P is a vector p containing the pivot indices. A pivot vector

documents that during the factorization the i-th row was interchanged with the p_i-th row (more formally, p stores a sequence of transpositions and their composition gives the permutation P). An implementation can compute

efficiently in a single loop:

  for i = 1,..,n
      swap b(i) and b(p(i))

Traversing the same loop backwards allows one to compute the inverse permutation

analogously through

  for i = n,..,1
      swap b(i) and b(p(i))

Note that this means: no extra vector is needed for storing the permutation of b instead vector b gets overwritten with P^-1b.

The coefficient matrix A can be overwritten with L and U during the factorization, that is

This is due to the fact that L is a lower unit triangular matrix, that means contains only ones on the diagonal. The total number of floating-point operation is of order .

Brief summary:

LU-factorization

    Input:   A      coefficient matrix

    Output:  A      overwritten with the LU factorization
             P      integer valued vector containing the pivots

Relevant routines in FLENS

The names of the functions are derived from corresponding LAPACK routines.

Examples Overview

The examples will briefly cover the following cases:

1. Single right-hand side, i.e. solve

2. Multiple right-hand sides, i.e. solve


Single Right-hand Side: Solve A*x=b

We choose as coefficient matrix

which is known from the discrete sine transform. Hence we already know what solution we get when choosing

as the right-hand side: That's right, it should be

#include <flens/flens.h>

using namespace flens;
using namespace std;

typedef GeMatrix<FullStorage<double, ColMajor> >    DGeMatrix;
typedef DenseVector<Array<double> >                 DDenseVector;
typedef DenseVector<Array<int> >                    IDenseVector;

int
main()
{
    int n = 4;

    // setup a coefficient matrix
    DGeMatrix    A(n,n);
    Index i,j;
    A(i,j) = sin(M_PI*i*j/(n+1));

    // setup a right-hand side
    DDenseVector b(n);
    b(i) = sin(M_PI*i/(n+1)) + 3*sin(3*M_PI*i/(n+1));

    // display A and b
    cout << "A = " << A << endl;
    cout << "b = " << b << endl;

    // solve A*x = b using a LU decomposition:
    //    b gets overwritten with the solution x
    //    P contains afterwards the pivot indices used in the LU factorization
    IDenseVector P(n);
    sv(A, P, b);
    cout << "x = A^{-1}*b = " << b << endl;
}

And here the result:

A = [4, 4]
   0.587785    0.951057    0.951057    0.587785 ;
   0.951057    0.587785   -0.587785   -0.951057 ;
   0.951057   -0.587785   -0.587785    0.951057 ;
   0.587785   -0.951057    0.951057   -0.587785 ;

b = [ 3.440955  -0.812299  -0.812299  3.440955 ]

x = A^{-1}*b = [ 1.000000  -0.000000  3.000000  0.000000 ]
